IRRInet Bermad S985 DC Latch Solenoid - 3 Wires
SKU 12.0002

IRRInet Bermad S985 DC Latch Solenoid - 3 Wires

WAS $0.00 - $0.00
WAS
$202.00
$202.00 - $202.00
$202.00
Excl. GST

We accept all major credit cards.

  • Mastercard
  • Shop Pay
  • Union Pay
  • Visa
  • Bank Transfer

The BERMAD S-985-3W-BB is a compact 3-Way Latching Solenoid Pilot Valve, comprised of two main components: a dry solenoid actuator and a 3-way hydraulic pilot valve. The actuator is neutralized from water damages by an isolating membrane, which hermetically isolates it from the water. The Model S-985-3W-BB consumes power only when switching positions, using a very short electric impulse. This prolongs life of batteries and enables solar recharging. The hydraulic base features a manual override and consists of a bracket for attaching to the valve or to a solenoid manifold.

    IRRInet Bermad S985 DC Latch Solenoid Specifications
    Base Ports: 1/8” NPT 1- Vent 2- Control Chamber 3- Pressure
    Valve Anchoring: By Screws (Self Tapping #8) at the Solenoid base
    Leads: 3 leads x 0.32 mm2 x 85 cm
    Operation Modes (electrical connections): + White
    Cable: Black PVC sheathed
    Operating Pressure Range: 0-10 bar
    Base Orifice Diameter: 2 mm
    Base Flow Factor: Pressure port Kv = 0.12 m3/h @ 1 bar ΔP; Cv = 0.14 GPM @1 psi ΔP Exhaust port Kv = 0.14 m3/h @ 1 bar ΔP; Cv = 0.16 GPM @1 psi ΔP
    Actuator Casing: Nylon
    Seals and Isolating Membrane: NBR
    Wetted parts: Nylon
    Base: Nylon
    Voltage Range: 12-50 VDC
    Coil Resistance: 2 Coils - 4.2 Ω On; 7.5 Ω Off
    Pulse Width: mSec.
    Required Capacitor: 4700μF

Disclaimer: Due to continued product development. Specifications and design subject to change without notice. Products depicted in this literature are for demonstration purposes only. Actual products offered for sale may vary in use, design, required attachments and safety features.
