Rain RN155 PLUS Solenoid Valve 25mm (1") 9V or 24 AC

Save 20%
$41.92 excl. GST $33.44 – $75.24 $26.75 – $60.19 excl. GST /

Select an option to add this to your cart.

The RN 155 solenoid valve is the ideal solution for residential and commercial irrigation with flow rates from 30 l/min to 90 l/min. Available in 24 Vac and 9 Vdc.

The presence of the ferrule of the patented Manifold system allows significant time savings during installation, but more importantly it allows the solenoid valve to be replaced in a matter of seconds, directly from inside the valve box and without the use of tools.

Rain RN155 PLUS Solenoid Valve | 25mm (1") 9V or 24 AC

Available for pickup

Usually ready in 24 hours

Parkland Products - Auckland

Available for pickup

Usually ready in 24 hours

322 Rosedale Road
Albany
AUK
Auckland 0632
New Zealand

094150300

9 Vdc Solenoid

9 Vdc Solenoid

Battery-operated controllers control 9Vdc latching solenoids. The control unit will send an electrical signal at the start of irrigation to open the solenoid valve and a signal at the end of irrigation to close the solenoid valve.
24 Vac Solenoid

24 Vac Solenoid

The controllers control 24 Vac normally closed solenoids. The control unit will supply the solenoid with a 24 Vac electrical signal for the entire irrigation time to open the electrovalve.
Manifold system

Manifold system

The patented Rain Manifold System allows easy installation of solenoid valves and during valve box maintenance allows quick removal of the solenoid valve.

RN 155 PLUS

Threads available: 3/4" M, 1" F, 1" M, 1" MxU
Solenoid type: 24 Vac - normally closed, 9 Vdc - latching
Manufacturing material: Glass fiber PA 6 30%
Solenoid inrush absorption 24 Vac: 0.43 A
Absorption at solenoid maintenance 24 Vac: 0.21 A
Operating flow rate: 30 - 150
Minimum pressure: 1 bar
Maximum pressure: 12 bar
Minimum operating flow rate: 30 l/min
Maximum operating flow rate: 150 l/min
Minimum operating temperature: 4°C
Maximum operating temperature: 70°C
Diaphragm type: In co-molded parts
Manual opening:

Disclaimer: Due to continued product development. Specifications and design subject to change without notice. Products depicted in this literature are for demonstration purposes only. Actual products offered for sale may vary in use, design, required attachments and safety features.

What is the knob in the middle of the solenoid valve for?

The central knob is the partializer and is used to adjust the water flow inside the solenoid valve. It is normally supplied fully open. It is often necessary to adjust the flow on sectors with dripline or microirrigation.
