RAIN NUVOLA Vision Irrigation Controller Wifi Connectivity Device

SKU: 200.1000004

Rain NUVOLA Vision Wifi Device

Name: Rain NUVOLA Vision Wifi Device
Brand: Rain
SKU: 200.1000004
Price: 262.74 NZD
Availability: InStock

Save 20%

$210.19 excl. GST ~~$262.74~~ $210.19 excl. GST /

Nuvola WiFi Vision is the device in the Vision range which allows smart controllers to be managed remotely via Internet connection. By utilising the Vision System remote connection, it allows for monitoring of irrigation functionality and scheduling anywhere, anytime via the Vision App, from smartphones, tablets and PCs.

By following the entire development and production process, we are able to guarantee the full reliability of the product, ensuring a valid after-sales support able to quickly satisfy any need or problem.

Bluetooth 5.0

The Bluetooth 5.0 data transmission technology built into the controllers enables the programming via the Vision App directly on your smartphone, or Webapp on your computer, when using a Nuvola Vision device.

Vision App

The Vision app is available on Google Play and App Store for smartphones and tablets.

Download Free Demo

Web App

The irrigation system can be accessed from any browser by accessing www.rainvision.it and entering your personal credentials or creating a new account.

Wi-Fi Connection

The Nuvola WiFi Vision device is compatible with 2.4 GHz Wi-Fi.

Weather Forecasts

Connecting to weather forecasts via OpenWeather.

NUVOLA MINI WIFI VISION

Power supply:	External transformer with Type C USB input 5 Vdc - 1A (not supplied)
Bluetooth:	Bluetooth 5.0 connection
Internet connection:	Compatible with Wi-Fi 2.4 GHz (802.11 b/g/n)
Maximum number of connected devices:	10

Disclaimer: Due to continued product development. Specifications and design subject to change without notice. Products depicted in this literature are for demonstration purposes only. Actual products offered for sale may vary in use, design, required attachments and safety features.

Nuvola Wifi / Bluetooth Vision Datasheet

Download View File

VISION APP: What happens if I lose the data connection when I click save and send? Will I have to repeat the programming?

Yes, a data connection is necessary for saving. If the connection fails, the application and system will not be updated.

VISION APP: What is the difference between PAUSE and OFF?

OFF: The control unit is turned off, indicating the end of the irrigation season.

PAUSE: Temporarily suspends operation for a few days, resuming programming after the pause period.

VISION APP I see the umbrella icon and the active zone icon. What does that mean?

It means that the area being irrigated does not have a rain sensor active, while the others do. So the umbrella icon (rain sensor icon) appears for those areas where it is active, while it does not appear for the area which is irrigating.

VISION APP: I can't find devices to pair. What should I do?

Try updating the app, clearing Bluetooth settings, removing and reinserting the battery, or restarting your smartphone.

VISION APP: How can I re-pair a controller accidentally deleted from Nuvola?

Go to the Nuvola screen, search for devices, and re-pair with the previously associated control unit.

VISION APP: The Vision App is not responding. What could be the problem?

It may be due to background apps, processor overload, or device conditions. Restart your smartphone to resolve the issue.

VISION APP If I delete the App with the devices I have associated, will they remain saved in the Account? So if I reinstall the App, will I still find the devices saved in my Account?

Yes, if you uninstall the App with the devices associated with this Account and then install it again, you will still see the devices associated with the Account.

BLUETOOTH: What is the maximum distance for pairing Vision devices via Bluetooth?

The average distance is 15 meters under standard conditions but can vary due to obstacles and environmental factors.

BLUETOOTH: How many smartphones can simultaneously connect to a Vision device via Bluetooth?

Only one device can connect at a time as Bluetooth communication is point-to-point.

BLUETOOTH: I entered the Bluetooth password but can't pair the device. What should I do?

Ensure no other account is paired with the device, clear Bluetooth data, restart your smartphone, and try again.

BLUETOOTH: I forgot the Bluetooth password. How can I reset it?

Scan the QR code on the device to reset it to the default password (000000).

BLUETOOTH: Is it compatible with older smartphones?

Compatibility depends on Bluetooth version. Devices with Bluetooth 5.0 are recommended.

INTERNET CONNECTION: What kind of Wi-Fi does Vision System use?

It uses standard Wi-Fi (WPA2) with SSID and password.

INTERNET CONNECTION: What distance should I maintain between Nuvola and the Wi-Fi router?

The range is typically 25-30 meters, depending on obstacles like walls or trees.

INTERNET CONNECTION: How many accounts can pair with one Nuvola?

Only one account can link to a Nuvola, but one account can manage multiple Nuvola devices.

INTERNET CONNECTION: Pairing with Nuvola takes too long. Why?

Wireless interference or environmental factors may delay pairing. Normally, it takes around 10 seconds under optimal conditions.

INTERNET CONNECTION: Can Vision controllers connect to the Internet for remote management?

Yes, they can connect via Nuvola devices.
